20
• 1.5.5.3 Internal Headers
Label Function Note Page
ATX12V1 ATX Power Connector 2 x 2 header 36
EATXPWR1 ATX Power Connector 12 x 2 header 36
SATA1,
SATA2,
SATA4,
SATA5,
SATA6
Serial ATA Connectors 1~6 7-pin header 39
CPU_FAN1 CPU Fan Connector 4 x 1 wafer, pitch 2.54mm 40
CHA_FAN1 Chassis Fan Connector 4 x 1 wafer, pitch 2.54mm 40
SYS_FAN1 System Fan Connector 4 x 1 wafer, pitch 2.54mm 40
JCASE1 Chassis Intrusion Connector 2 x 1 header, pitch 2.54mm 41
SPDIF_O Digital Audio Connector 4 x 1 header, pitch 2.54mm 41
FPAUD1 Front Panel Audio Connector 5 x 2 header, pitch 2.54mm 42
JAMP1 Amplifier Connector 4 x 1 header, pitch 2.54mm 43
USB67
USB89
USB1011
USB1213
USB 2.0 Connector 5 x 2 header, pitch 2.54mm 43
COM1,
COM2,
COM3,
COM4
Serial Port Connector 1,2,3,4 5 x 2 header, pitch 2.00mm 44
LPT1 Parallel Port Connector 13 x 2 header, pitch 2.00mm 44
F_PANEL System Panel Connector 5 x 2 header, pitch 2.54mm 45
LANLED1 LAN LED header 5 x 2 header, pitch 2.54mm 45
DIO1 Digital I/O Connector 5 x 2 header, pitch 2.00mm 46
SPI_CN SPI pin header (Factory use only) 4 x 2 header, pitch 2.54mm 46
