75.5957.02 EAGLE FAMILY 20181130 Page 3 of 4
XXS
0.5 s
XS
1 s
auto
< 10 ft
low
bi
A
S
2 s
open
> 10 ft
normal
uni
P
>
3 s
closed
high
uni
MTF
>
4 s
>
uni
AWAY
>
5 s
>
MTF &
AWAY
>
6 s
>
L
7 s
L
XL
8 s
XL
XXL
9 s
highest
+
7 ft
7 ft
5
6
10 ft
10 ft
MECHANICAL ADJUSTMENTS (cont.)
SETTINGS (by remote control or push-buttons)
If desired, adjust the antenna angle (laterally and/or vertically) to position the detection field.
When mounting at the maximum height, BEA recommends a 15° tilt angle.
Observe antenna type (narrow or wide) in the illustrations below.
Program the sensor for the desired application.
When mounting at the maximum height, BEA recommends the following:
Immunity = low
Zone Size = XXL
LATERAL ADJUSTMENT VERTICAL ADJUSTMENT
ZONE SIZE
IMMUNITY FILTER
DETECTION MODE
OUTPUT
CONFIGURATION
HOLD-OPEN TIME
MOUNTING
HEIGHT
DOOR CONTROL
bi = two-way detection
uni = one-way detection towards sensor
uni MTF = one-way detection with motion tracking feature
uni AWAY = one-way detection away from sensor
A = active output (NO-contact); relay energizes upon detection
P = passive output (NC-contact); relay de-energizes upon detection
Standard Eagle default = < 10 ft
High-mount Eagle default = > 10 ft
open = the sensor detects constantly. The LED is ON.
closed = the sensor is in standby and does not detect. The LED is OFF.
FACTORY VALUES
USING REMOTE CONTROL: USING PUSH-BUTTONS: > 2 sec
WIDE WIDE
NARROW NARROW
RESETTING TO FACTORY VALUES
ACCCESS CODE
The access code (1 to 4 digits) is recommended to set sensors installed close to each other.
SAVING AN ACCESS CODE:
DELETING AN ACCESS CODE:
Once you have saved an access code, you always need to enter this code to unlock the sensor.
If you forget the access code, cycle the power. For the first minute, you can access the sensor without an access code.
