BEA FALCON - Sensing Field Configuration; Sensing Field Visualization; LED Status Indicators

XXS XS S > > > > L XL XXL
0.5 s 1 s 2 s 3 s 4 s 5 s 6 s 7 s 8 s 9 s
3 4
5 6
1
2
P
A
(7)
(0)
(1)
(2)
(1)
FALCON
bi uni
POSSIBLE SETTINGS BY REMOTE CONTROL
FIELD SIZE
OUTPUT
CONFIGURATION
A = active output (relay active when detection)
P = passive output (relay active when no detection)
DETECTION MODE
uni
AWAY
FACTORY VALUES
RESETTING TO FACTORY VALUES:
Avoid proximity to neon
lamps or moving objects.
Do not cover the sensor.
DETECTION FILTER
HOLD-OPEN TIME
Avoid vibrations. Only open the sensor
when the cable needs to
be replaced.
Wall mounting
Ceiling mounting Bracket dimensions
TO START OR END AN ADJUSTMENT SESSION, press and hold either push button until the LED flashes or
stops flashing.
1 FIELD SIZE
Parameter n°
2 HOLD-OPEN TIME
3 OUTPUT CONFIGURATION
4 DETECTION MODE
5 DETECTION FILTER
Value (factory values)
TO SCROLL THROUGH THE
PARAMETERS, press
the right push button.
TO CHANGE THE VALUE OF
THE CHOSEN PARAMETER,
press the left push button.
TO RESET TO FACTORY VALUES, press and hold both push buttons until both LEDs flash.
POSSIBLE SETTINGS BY PUSH BUTTONS
MOUNTING TIPS
DIMENSIONS (in mm)
bi = two-way detection
uni = one-way detection towards sensor
uni AWAY = one-way detection away from sensor
• The sensor cannot be used for purposes other than its intended use.
• The manufacturer of the door system incorporating the sensor is responsible for compliance of the system
to applicable national and international regulations and safety standards.
• The installer must read, understand and follow the instructions given in this manual. Improper installation
can result in improper sensor operation.
• The manufacturer of the sensor cannot be held responsible for injury or damage resulting from incorrect
use, installation or inappropriate adjustment of the sensor.
