7. SYSTEM OVERVIEW
IPC@CHIP family microcontroller has a system configuration based on the ISA architecture with
some changes: No ISA-Bus, no Video-Interface, no Keyboard Interface, programming of Serial Ports,
DMA, PIC and Timer is different from standard IBM PC.
This section provides an overview of the system memory configuration and basic I/O.
7.1 Memory map
SC12 Memory I/0 map
FFFFFh
Bootloader
FFFFh
FEFFFh
Reserved
0700h
Flash Disk
06FFh
PCS6#
XXXXXh* 0600h
XXXXXh* 05FFh
PCS5#
@CHIP RTOS
0500h
04FFh
80400h
Reserved
80000h
Reserved
0400h
7FFFFh 03FFh
PCS3#
0300h
02FFh
PCS2#
Working Memory
0200h
512Kbyte RAM
01FFh
PCS1#
0100h
00FFh
PCS0#
00000h 0000h
* depends on the BIOS version
