IPC@CHIP - SC12
Hardware Manual v1.1 [05.11.2002]
©BECK IPC GmbH page 7 of 28
4. PIN FUNCTIONS
Pin Terminology
The following terms are used to describe the pins:
Input (I) - An input-only pin.
Input (IS) - An input-only pin with Schmitt Trigger.
Output (O) - An output-only pin.
Input/Output (I/O) - A pin that can be either input or output.
4.1 Address / Data bus
Pin Name Type Function
A[0..2] O
Address Bus (output, three-state)
These pins supply nonmultiplexed memory or I/O addresses to the system.
During a bus hold or reset condition, the address bus is in a high-
impedance state.
A0–A2 will serve as the nonmultiplexed address bus for external
peripherals. A0-A2 covers an address range of 8 Byte max.
AD[0..7] I/O
Multiplexed Address and Data Bus (input/output, three-state, level-
sensitive)
These time-multiplexed pins supply partial memory or I/O addresses, as
well as data, to the system. This bus supplies the low-order 8 bits of an
address to the system during the first period of a bus cycle (t1), and it
supplies data to the system during the remaining periods of that cycle (t2 ,
t3 , and t4). In 8-bit mode, AD7–AD0 supplies the data for both high and low
bytes.
During a bus hold or reset condition, the address and data bus is in a high-
impedance state.
ALE O
Address Latch Enable (output)
This pin indicates to the system that an address appears on the address
and data bus (AD7–AD0). The address is guaranteed to be valid on the
trailing edge of ALE.
ALE is three-stated and held resistively Low during a bus hold condition. In
addition, ALE has a weak internal pulldown resistor that is active during
reset, when it is enabled by software.
RD# O
Read Strobe (output, three-state)
This pin indicates to the system that the microcontroller is performing a
memory or I/O read cycle. RD is guaranteed to not be asserted before the
address and data bus is floated during the address-to-data transition. RD
floats during a bus hold condition.
WR# O
Write Strobe (output)
This pin indicates to the system that the data on the bus is to be written to a
memory or I/O device. WR floats during a bus hold or reset condition.
