IPC@CHIP - SC12
Hardware Manual v1.1 [05.11.2002]
©BECK IPC GmbH page 27 of 28
11. ERRATA LIST
(Changes since last document Hardware Manual v1.0)
Page 6, Chapter 3: PIN CONFIGURATION:
Wrong pin names at pin18 and pin 19
Page 10, Chapter 4.6: LINK LED
The traffic hi-pulse width and the sink output voltage were not right.
Extenal component connection to this pin.
Page 24, Chapter 10.1 NMI / Reset-In / Link-LED
Some values were hard to read
Page 19, Chapter 7.3 Watchdog
Wrong watchdog timeout period
Page 25, Chapter 10.2 Link-LED / Reset
The inputs of the comparator were interchanged
Page 14, Chapter 4.10 Reset, Power Fail Generator
Note added to the time to save retentive data
Page 18, Chapter 7.1 Memory map
Memory of Flash Disk and @CHIP RTOS were not right
Page 3, Chapter 1.0 BASIC SPECIFICATION
Added note to flash memory cycles
