Beckhoff AX5000 Series Start-Up

5 Installation BECKHOFF Drive Technology
36 Version 2.5 AX5000
5.3 Motors and cables
With longer motor cables the resulting commutation currents can affect the control quality
and lead to EMC faults. Use the tables below to check whether motor chokes or mains filters
have to be used in your application. When selecting the control cabinet ensure that there is
adequate space for motor chokes, mains filters, etc.
Lay the power and signal cables in separate metal cable ducts or, if both types of cable use
the same metal cable duct, make sure there is an earthed metal dividing wall between the
cables.
Note
Motor chokes
For the series AX5160 up to AX5193 motor chokes are not required. The
values only apply for single devices.
Maximum cable length (including extensions) for a rated motor voltage up to 480 V
Mains choke
AX5160
AX5172
AX5190
1)
AX5191
2)
AX5192
2)
AX5193
3)
C2
C3
C2
C3
C2
C3
C2
C3
C2
C3
C2
C3
AX2090
ND50-0060
-
50 m
4) 5)
- - - - - - - - - -
AX2090
ND50-0072
- - -
50 m
4) 6)
- - - - - - - -
AX2090
ND50-0090
- - - - -
25 m
7)
- - - - - -
AX2090
ND50-0110
- - - - - - -
25 m
7)
- - - -
AX2090
ND50-0143
- - - - - - - - -
25 m
7)
- -
AX2090
ND50-0170
- - - - - - - - - - -
25 m
7)
1)
For compliance with EN 61800-3 only with mains filter AX2090-NF50-0100.
2)
For compliance with EN 61800-3 only with mains filter AX2090-NF50-0150.
3)
For compliance with EN 61800-3 only with mains filter AX2090-NF50-0180.
4)
Without mains choke and without external mains filter up to max. 25m
5)
Only with additional external mains filter AX209-NF50-0063
6)
Only with additional external mains filter AX209-NF50-0090
7)
Without compliance with EN 61800-3 the max, motor cable length amounts to 100 m.
