Beckhoff BC3150 User Manual

Programming
BC315072 Version: 2.1.0
5.12.2.5 System information type
TYPESYSTEMINFOTYPE
STRUCT
runTimeNo:BYTE;
projectName:STRING(32);
numberOfTasks:BYTE;
onlineChangeCount:UINT;
bootDataFlags:BYTE;
systemStateFlags:WORD;
END_STRUCT
END_TYPE
Key
runTimeNo: indicates the number of the runtime system (1).
projectName: project name as STRING.
numberOfTasks: number of tasks contained in the runtime system (max. 1).
onlineChangeCount: number of online changes since the last complete download.
bootDataFlags: Reserved
systemStateFlags: Reserved.
Development environment Target platform PLC libraries to be linked
TwinCAT v2.9.0 BCxx50, BC9x20 Controller TcBaseBCxx50.lbx
5.12.2.6 ADS
5.12.2.6.1 Local ADS Port Numbers
Port number Description
100 [}72]
dec
Reading and writing of registers and tables from the coupler and the complex Bus
Terminals
801 [}72]
dec
Local PLC process image
5.12.2.6.2 ADS services
Local process image task 1 port 800 or 801
Data can be read from and written to the local process image. If it is necessary for outputs to be written, it is
important to ensure that they are not used by the local PLC, because the local controller will overwrite these
values. The data are not associated with a watchdog, and therefore must not be used for outputs that would
have to be switched off in the event of a fault.
Index group Meaning Index offset (value range)
0xF020 Inputs 0...2047
0xF030 Outputs 0...2047
0x4020 Flags 0...4095
ADS services
AdsServerAdsState
Data type(read only) Meaning
String Start - the local PLC is running
Start - the local PLC is stopped
