Assembly dimensions
7 Assembly dimensions
For the assembly dimensions of the Control Panels please visit our homepage. Here you will find the
actual drawings using the link:
http://download.beckhoff.com/download/Technical_Drawings/Industrial_PC/Control_Panel/CP29xx
Notice mounting orientation
Warning
The assembly of the unit must take place with the orientation diagrammed here.
