Technical Data
8 Technical Data
Risk of explosion!
Danger
Do not use the Control Panel in areas of explosive hazard!
Pixel errors
Note
Pixel errors in the TFT display are production-caused and represent no complaint-
reason!
Anomalies of the Touchscreen
Note
Anomalies of the touchscreen sensor are production-caused and represent no
complaint-reason!
Product name CP29xx-0000/ -0010
Dimensions (B x H x T) See chapter Assembly dimensions
Weight CP2907: 1.5 kg CP2918: 5.1 kg
CP2912: 3.0 kg CP2919: 5.4 kg
CP2915: 3.7 kg CP2921: 5.9 kg
CP2916: 4.2 kg CP2924: 7.2 kg
Supply voltage 24 V
DC
(20.4 – 28.8 V
DC
)
Power consumption CP2907: max. 12 W CP2918: max. 25 W
CP2912: max. 16 W CP2919: max. 25 W
CP2915: max. 20 W CP2921: max. 35 W
CP2916: max. 22 W CP2924: max. 45 W
UL-compliance
(in progress)
• Using a power supply class 2 or
• Fuse protection with 4 A, according to UL 60950.2
chapter 2.5, table 2C
CP29xx-0000:
Integrated DVI/USB extension
technology
•
•
•
DVI-E and USB-E 2.0 enable remote panel operation at a distance
of up to 50 m from the PC
USB-E 2.0 transmits USB 2.0 with 480 Mbit/s
DVI-E input is compatible to the standard DVI output of a PC
CP29xx-0010:
Integrated CP-Link 4 technology
•
•
•
enables remote panel operation at a distance of up to 100 m from
the PC via a CAT.6
A cable
integrated or separate 24 V DC power supply
CP-Link 4 transmits USB 2.0 with 100 MBit/s
Interfaces CP29xx-0000 2-Port-USB-3.0/ USB 2.0, see chapter Interfaces CP29xx-0000
Interfaces CP29xx-0010 2-Port-USB-2.0 interface
Protection class Front side IP65, rear side IP20
Shock resistance
(Sinusoidal vibration)
EN 60068-2-6: 10 to 58 Hz: 0.035 mm
58 to 500 Hz: 0.5 G (~ 5 m/ s
2
)
Shock resistance (Shock) EN 60068-2-27: 5 G (~ 50 m/ s
2
), duration: 30 ms
EMC compatibility Resistance to interference conforms to EN 61000-6-2
EMC compatibility Emission of interference conforms to EN 61000-6-4
Permissible ambient temperature Operation: 0°C to +55°C (CP29xx-0000) 0°C to +50°C (CP29xx-0000)
Transport/ storage: -20°C to +70°C
Permissible relative humidity to 95%, no condensation
Transport and storage The same values for atmospheric humidity and shock resistance are
to be observed during transport and storage as in operation. Suitable
packaging of the Panel PC can improve the resistance to impact
during transport.
Certifications CE; UL in progress
CP29xx 27
