Product overview
EK1122, EK15xx 21Version: 3.4
3.2.1.2 Technical data
Technical data EK1122-0008
Task within the EtherCAT system Coupling of EtherCAT junctions via M8
Transmission medium Ethernet/EtherCAT-cable (min. CAT 5), shielded
Cable length between two stations 100m (100BASE-TX)
Protocol / Baud rate EtherCAT
Configuration not required
Bus interface 2 x M8
Delay approx. 1µs
Power supply from E-bus
E-Bus current consumption typ. 220mA
E-bus power supply (5 V)
(at higher current consumption the EL9410 power feed
terminal can be used in addition)
max. 2000mA (-25°C ... +55°C)
max. 1000mA (> +55°C)
Dimensions (W x H x D) approx. 26mm x 100mm x 52mm (width aligned:
23mm)
Weight approx. 65g
Permissible ambient temperature range during
operation
-25°C ... +60°C
(extended temperature range)
Permissible ambient temperature range during storage -40°C ... + 85°C
Permissible relative humidity 95%, no condensation
Mounting [}43]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
cULus [}69]
ATEX [}49]
