Commissioning/application notes

EK1122, EK15xx54 Version: 3.4

6.3 Application notes fiber optic junction

Mounting rail installation

Mounting

Please ensure that the EK1521, EK1521-0010 engages properly on the DIN rail. See mounting rail

installation [}46] and recommended mounting rails [}47].

6.3.1 Settings and port assignment

For normal operation the EK1521, EK1521-0010 can be used with default settings.

The port ID used in the TwinCAT System Manager is mapped on the EK1521, EK1521-0010 as follows:

Fig.44: Port ID for EK1521, EK1521-0010
