Commissioning/application notes

EK1122, EK15xx 51Version: 3.4

6 Commissioning/application notes

Mounting rail installation

Mounting

Please ensure that the EK1122 engages properly on the DIN rail. See mounting rail installation

[}46] and recommended mounting rails [}47].

6.1 Application notes RJ45 junction

6.1.1 Settings and port assignment

For normal operation the EK1122 can be used with default settings.

The port ID used in the TwinCAT System Manager is mapped on the EK1122 as follows:

Fig.40: EK1122 port ID
