Mounting and wiring

EK1122, EK15xx 45Version: 3.4

5.3 Nut torque for connectors

Fig.36: X1 and X2 of EK1122-0008

For usage of the EtherCAT connectors M8 of EK1122-0008 the following have to be noticed:

M8 connectors

It is recommended to pull the M8 connectors tight with a nut torque of 0.4 Nm. When using the torque control

screwdriver ZB8800 is also a max. torque of 0.5Nm permissible.

Fig.37: EtherCAT Box with M8 connectors
