Product overview
EK1122, EK15xx 23Version: 3.4
3.3.1.2 Technical data
Technical data EK1521
Task within the EtherCAT system Coupling of EtherCAT junctions
Transmission medium Multimode glass fiber (MM)
Transceiver wavelength 1300nm
Cable length between two Bus Couplers 2,000m (100BASE-FX) multimode glass fiber
Protocol / Baud rate All EtherCAT protocols / 100Mbaud
Configuration no address and configuration settings required
Bus connection 1 x SC Duplex connector
Power supply from E-bus
Current consumption typ. 350mA
Dimensions (W x H x D) approx. 26mm x 100mm x 52mm (width aligned:
23mm)
Weight approx. 70g
Permissible ambient temperature range during
operation
-25°C ... +60°C
(extended temperature range)
Permissible ambient temperature range during
storage
-40°C ... + 85°C
Permissible relative humidity 95%, no condensation
Mounting [}43]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
ATEX [}49]
cULus [}69]
