Beckhoff EK15 Series User Manual

Product overview
EK1122, EK15xx 27Version: 3.4
3.4.1.2 Technical data
Technical data EK1561
Task within the EtherCAT system Coupling of EtherCAT junctions via POF
Transmission medium Polymeric Optical Fiber
Transceiver wavelength 650nm
Laser class 1, see note [}69]
Cable length between two stations max. 50m (100BASE-FX) POF
Protocol / Baud rate All EtherCAT protocols / 100Mbaud
Configuration no address and configuration settings required
Bus connection 1 x versatile link for POF duplex connector
(connector set ZS1090-0008)
Delay approx. 1µs
Power supply from E-bus
E-Bus current consumption typ. 200mA
Dimensions (W x H x D) approx. 26mm x 100mm x 52mm (width aligned:
23mm)
Weight approx. 65g
Permissible ambient temperature range during
operation
-25°C ... +60°C
(extended temperature range)
Permissible ambient temperature range during
storage
-40°C ... + 85°C
Permissible relative humidity 95%, no condensation
Mounting [}43]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
cULus [}69]
