66 ─── Version: 1.0XPlanar
9.1.3.1Mover alignment
9.1.3.1
1
Number Name
1 XY axes of the mover
Point of origin of the tile
When placing the movers, make sure that the XY axes of the
mover[1] correspond to the XY axes of the tile. The point of origin of
the tile is used for orientation. For more information see chapter on
"Mounting", [Page45].
Also make sure that you position the movers as parallel as possible
to the outer edges of the tiles.
