17. MIDI NRPN Commands
NRPN (Non-Registered Parameter Numbers) are a special type of MIDI
communication that allows control of parameters that are not dened in the
basic MIDI standard. NRPNs work by using groups of dened controller messages
to expand the number of available parameter numbers and also to extend the
maximum resolution. For more information on NRPNs and their implementation
please consult the MIDI Manufacturers Association at www.midi.org. For
specic information regarding the support of NRPN data within any Audio/
MIDI application please consult the manufacturer.
An NRPN message consists the following byte sequence
The Data Entry (MSB) message is optional and can be ignored for switch
parameters or any parameters which have a range of 0-127 or less.
Note : When Running Status is taken into account, this bytes sequence is reduced
to.. B0, 63, aa, 62, bb, 06, cc, 26, dd.
Note : Once the NRPN parameter ID has been selected with the rst two
messages if the previously selected parameter is changed again (i.e. user
is moving a single control) then the rst two messages can be omitted
leaving just the Data Entry LSB & MSB messages.
Note : The DeepMind 12 treats NPRNs from USB, Wi-Fi & the physical MIDI ports
separately i.e. it has a 'selected NPRN parameter' for each interface.
The NRPN implementation of the DeepMind 12 is listed in the table below:
MSB LSB 14-bit Parameter Name Range Notes
0 0 00 LFO 1 Rate 0-255 —
0 1 01 LFO 1 Delay / Fade 0-255 —
0 2 02 LFO 1 Shape 0-6 Sine (0), Triangle (1), Square (2), Ramp Up (3), Ramp Down (4), Sample & Hold (5), Sample & Glide (6)
0 3 03 LFO 1 Key Sync 0-1 O (0), On (1)
0 4 04 LFO 1 Arp Sync 0-1 O (0), On (1)
0 5 05 LFO 1 Mono Mode 0-1 Poly (0) Mono (1) or SPREAD-1(2) to SPREAD-254(255)
0 6 06 LFO 1 Slew Rate 0-255 —
0 7 07 LFO 2 Rate 0-255 —
0 8 08 LFO 2 Delay / Fade 0-255 —
0 9 09 LFO 2 Shape 0-6 Sine (0), Triangle (1), Square (2), Ramp Up (3), Ramp Down (4), Sample & Hold (5), Sample & Glide (6)
0 10 10 LFO 2 Key Sync 0-1 O (0), On (1)
0 11 11 LFO 2 Arp Sync 0-1 O (0), On (1)
0 12 12 LFO 2 Mono Mode 0-255 Poly (0) Mono (1) or SPREAD-1(2) to SPREAD-254(255)
0 13 13 LFO 2 Slew Rate 0-255 —
0 14 14 OSC 1 Range 0-2 16' (0), 8' (1), 4' (2)
0 15 15 OSC 2 Range 0-2 16' (0), 8' (1), 4' (2)
0 16 16 OSC 1 PWM Source 0-5 Manual (0), LFO 1 (1), LFO 2 (2), VCA Env (3), VCF Env (4), Mod Env (5)
0 17 17 OSC 2 Tone Mod Source 0-5 Manual (0), LFO 1 (1), LFO 2 (2), VCA Env (3), VCF Env (4), Mod Env (5)
0 18 18 OSC 1 Pulse Enable 0-1 O (0), On (1)
0 19 19 OSC 1 Saw Enable 0-1 O (0), On (1)
0 20 20 OSC Sync Enable 0-1 O (0), On (1)
0 21
21 OSC 1 Pitch Mod Depth 0-255 —
0 22 22 OSC 1 Pitch Mod Select 0-6 LFO 1 (0), LFO 2 (1), VCA Env (2), VCF Env (3), Mod Env (4), LFO 1 Unipolar (5), LFO 2 Unipolar (6)
0 23 23 OSC 1 Aftertouch > Pitch Mod Depth 0-255 —
0 24 24 OSC 1 Mod Wheel > Pitch Mod Depth 0-255 —
0 25 25 OSC 1 PWM Depth 0-255 —
0 26 26 OSC 2 Level 0-255 —
0 27 27 OSC 2 Pitch 0-255 —
0 28 28 OSC 2 Tone Mod Depth 0-255 —
0 29 29 OSC 2 Pitch Mod Depth 0-255 —
0 30 30 OSC 2 Aftertouch > Pitch Mod Depth 0-255 —
0 31 31 OSC 2 Mod Wheel > Pitch Mod Depth 0-255 —
0 32 32 OSC 2 Pitch Mod Select 0-6 LFO 1 (0), LFO 2 (1), VCA Env (2), VCF Env (3), Mod Env (4), LFO 1 Unipolar (5), LFO 2 Unipolar (6)
0 33 33 Noise Level 0-255 —
