Behringer DEEPMIND 12 User Manual

139 DeepMind 12 User Manual
MSB LSB 14-bit Parameter Name Range Notes
1 28 156 Arp Mode 0-10
Up (0), Down (1), Up&Down (2), Up Inv (3), Down Inv (4), Up&Down Inv (5), Up Alt (6), Down Alt (7), Random (8),
As Played (9), Chord (10)
1 29 157 Arp Rate (tempo) 0-255 20 bpm (0) to 275 bpm (255)
1 30 158 Arp Clock 0-12 See Arpeggiator clock divider table
1 31 159 Arp Key Sync 0-1 O (0), On (1)
1 32 160 Arp Gate Time 0-255
1 33 161 Arp Hold 0-1 O (0), On (1)
1 34 162 Arp Pattern 0-64 None (0), Preset-1 (1) ... User-1 (33) ... User-32 (64 )
1 35 163 Arp Swing 0-25 50% (0) to 75% (25)
1 36 164 Arp Octaves 0-5 1 to 6 Octaves
1 37 165 FX Routing 0-9 SeeFX Connection Modes
1 38 166 FX 1 Type 0-33 See FX Type list
1 39 - 50 167 -178 FX 1 Params 0-255 FX Slot 1 Parameters
1 51 179 FX 2 Type 0-33 See FX Type list
1 52 -63 180 -191 FX 2 Params 0-255 FX Slot 2 Parameters
1 64 192 FX 3 Type 0-33 See FX Type list
1 65 - 76 193 -204 FX 3 Params 0-255 FX Slot 3 Parameters
1 77 205 FX 4 Type 0-33 See FX Type list
1 78 - 89 206 -217 FX 4 Params 0-255 FX Slot 4 Parameters
1 90 218 FX 1 Output Gain 0-150 —
1 91 219 FX 2 Output Gain — —
1 92 220 FX 3 Output Gain — —
1 93
221 FX 4 Output Gain 0-150 Output gain for FX slots 1-4
1 94 222 FX Mode 0-2 Insert (0), Send (1), Bypass (2)
1 95 - 111 223 -239 Program Name 0-127 Null terminated Program name. 16(+1) char ASCII string.
1 112 240 Program Category 0-16 See program category table
1 113 241 Program Transpose 80 -176 -48 (80) ... 0 ( 128) ... 176 (+48 )
18. Global Commands
Parameter Name Range Description
MIDI Channel 0-16 Sets MIDI Rx / Tx channel. 0 = All, 1 = Ch1 ... 16 = Ch16
Keyboard Local 0-1 Sets the keyboard, mod and pitch wheels 'local' mode, i.e whether they control the synth (1) or just send MIDI (0)
Fader Local 0-1 Sets the fader local mode, i.e whether the faders control the synth (1) or just send MIDI (0)
Global Tune 0-255 0=-128 cents, 128=0 cents 255 = +127 cents
MIDI Clock Source 0-2 Sets the source for the Arp clock. MenuItemMidiClock_e (Internal, MIDI, USB )
MIDI Program Change Mode 0-2 Sets whether the synth receives or sends Program changes or both. MenuItemProgramChangeMode_e (Rx, Tx, Both)
USB Control mode 0-2
Sets whether the synth sends CC (eg for controlling a soft synth) or NRPN messages to USB (for our iOS App) - this is set automatically when an
app notify message is received.
MIDI Control mode 0-2
Sets whether the synth sends CC (eg for controlling another synth) or NRPN messages to MIDI (for our VST App) - this is set automatically when
an app notify message is received.
MIDI Soft Thru 0-1 Sets whether the synth forwards messages received on MIDI In to MIDI Out (O, On ).
USB to MIDI 0-1 Sets whether the synth forwards messages received on USB to MIDI Out (O, On )
MIDI to USB 0-1 Sets whether the synth forwards messages received on MIDI In to USB (O, On )
Fixed Velocity 0-1 Sets whether the keyboard sends xed (1) or dynamic (0) velocity as part of a Note On message.
Velocity 0-127 Sets the velocity sent when in xed mode.
Velocity Curve 0-127 (-64 : +63 - TBD ) sets the curve used to convert key velocity into MIDI note velocity - adjust to suit style of playing
Transpose 0-96 (-48 : 48 ) set the keyboard transpose amount (aects local & MIDI operation)
Aftertouch Curve 0-127 (-64 : +63 TBD) sets the curve used to convert key pressure into MIDI aftertouch - adjust to suit style of playing
Pedal CC 0-3 Sets the MIDI Controller sent by the foot controller pedal input ( Foot Control (CC4), Breath (CC3), Volume (CC7), Expression (CC11)
Sustain CC 0-3 Sets the polarity and function of the sustain pedal switch (Normal+, Normal-, Arp(+), Arp(-))
Fader Pick Up Mode 0-2 Set the Fader pick-up mode (Relative, Pass-thru, Jump )
LCD Brightness 0-9 Sets the LCD brightness in 10% steps (10% to 100%)
LCD Contrast 0-9 Sets the LCD contrast in 10% steps (10% to 100%)
Arp Send to MIDI 0-1 Enables transmission of arpeggiator output to MIDI out (both USB and physical MIDI)
Send NRPN on load 0-2
(may be removed for release version) - Dumps NRPN values when a new program is loaded (mainly for ctrlr)MenuItemSendNrpnOnLoad_e (O,
MIDI, USB)
Keyboard Octave 0-7 (0-MAX_KEYBOARD_OCT) Sets octave shift for keyboard. At 0, left most key is C0
