Behringer DEEPMIND 12 User Manual

140 DeepMind 12 User Manual
19. MIDI SysEx Commands
SysEx (System Exclusive) are a special type of MIDI communication that allows
control of parameters and settings on a device/manufacturer specic basis.
For more information on SysEx and its implementation please consult the MIDI
Manufacturers Association at www.midi.org. For specic information regarding
the support of SysEx data within any third party Audio/MIDI applications please
consult the manufacturer.
The SysEx implementation of the DeepMind 12 is described in the following
sections:
19.2.1 Universal System Exclusive Message (Device
Inquiry)
This message can be used to detect the presence of the synth and to get the
current global MIDI channel setting (also used as a SysEx Device ID when
addressing the synth).
DEVICE ENQUIRY SysEx REQUEST
MIDI Bytes
Description
F0 System Exclusive Status Byte
7E Non Real Time Message Code
nn or 7F Device ID (0-15) or 7F for broadcast
06 General Information Message Code
01 Identity Request Message Code
F7 End of System Exclusive
DEVICE ENQUIRY SysEx RESPONSE
MIDI Bytes Description
F0 System Exclusive Status Byte
7E Non Real Time Message Code
nn Device ID of unit 0-15
06 General Information Message Code
01 Identity Reply Message Code
00, 20, 32 Behringer Manufacturers ID
20 DeepMind12 Product Family ID Code (LSByte)
00 DeepMind12 Product Family ID Code (MSByte)
01 DeepMind12 Family Member ID Code (LSByte)
00 DeepMind12 Family Member ID Code (MSByte)
jn
Main Software Version Revision Information j = minor revision
(0-7) n=major revision (0-15)
00 Reserved
ii Voice Software Major Version Number (0-127)
nn Voice Software Minor Version Number (0-127)
F7 End of System Exclusive
01 Identity Request Message Code
F7 End of System Exclusive
19.2.2 App Notify Messages
This message is transmitted to the synth to identify that there is a control app
connected on a particular MIDI interface. The synth, on receiving this message
will ensure that NPRN and SysEx messages are enabled on this interface and
then will reply with device ID, rx/tx channels and interface ID of the interface
which the app notify message was received on. When an app is connected on an
interface, the unit sends out additional SysEx messages such as key down & voice
allocation update messages
APP NOTIFY REQUEST
MIDI Bytes Description
F0 System Exclusive Status Byte
00, 20, 32, Behringer Manufacturers ID
20 DeepMind 12 Model ID
0d Device ID 0-15
00 Control App Notify
rr reserved
F7 End of System Exclusive
APP NOTIFY RESPONSE
MIDI Bytes Description
F0 System Exclusive Status Byte
00, 20, 32 Behringer Manufacturers ID
20 DeepMind 12 Model ID
0d Device ID 0-15
10 Control App Notify Response
rx Midi Receive Ch 0-16 (All, 1-16)
tx Midi Transmit Ch 0-15 (1-16)
if Interface ID (0=MIDI 1=USB 2=Wi)
cb Currently selected bank (0-7)
cp Currently selected program (0-127)
F7 End of System Exclusive
00 Reserved
ii Voice Software Major Version Number (0-127)
nn Voice Software Minor Version Number (0-127)
F7 End of System Exclusive
01 Identity Request Message Code
F7 End of System Exclusive
