68 DeepMind 12 User Manual
The fader position, current value, and stored value for the OSC 2 PITCH fader
is shown on the PROG screen. There is also a visualization of the pitch setting
as shown below:
Note: The centre horizontal section of the line shown in the visualization,
highlights the ne resolution that is available around the centre point. Here
the units of adjustment will change from semitones to cents, giving you ne
adjustment when close to the pitch of OSC1.
8.3.8 OSC 2 LEVEL FADER
• The OSC 2 LEVEL fader controls the LEVEL of the OSC 2 SQUARE waveform.
The level setting can be used to adjust the balance between OSC 1 and OSC 2.
The balance between OSC 1 and OSC 2 when used together, allows you to
increase the sonic palette of the program. Combining oscillators can be
done to create new waveforms and alter the harmonic structure of the
program. By slightly detuning the oscillators, you can create bigger, thicker
sounds. Detuning in small and equal increments will not make a noticeable
dierence to the base pitch of the sound, but as you increase the amount of
detuning it will start to become noticeable. Detuning can be done in musical
intervals for example a fth, or a seventh, to add harmony to a pad sound, or
even an entire octave to give a bass program a deeper sound.
The OSC 2 LEVEL can be set to O, or its operational range is from -48 to
0.0 dB.
The default OSC 2 LEVEL setting is 0.
The fader position, current value, and stored value for the OSC 2 LEVEL fader
is shown on the PROG screen. There is also a visualization of the waveform as
shown below.
Note: It is important to note that the visualization shows the combination of
OSC 1 and OSC 2.
OSC 2 LEVEL
0FF
-12.0 dB
0.0 dB
To Next Page
