9 DeepMind 12 User Manual
(12) ENVELOPE - these are the three envelopes used to modulate
other parameters.
A [ATTACK]- controls the attack time of the envelope.
D [DECAY] - controls the decay time of the envelope.
S [SUSTAIN] - controls the sustain level of the envelope.
R [RELEASE] - controls the release time of the envelope.
VCA - selects the envelope used to control the voltage controlled amplier.
VCF - selects the envelope used to control the voltage controlled lter.
MOD - selects the envelope used for user specic modulation.
CURVES - changes the ADSR controls to aect the associated curves for
each stage of the envelope.
(13) VOICES - these LEDs show which voices are active as keys are played.
(14) OCTAVE - these LEDs show the octave shift applied to the keyboard.
(15) PORTAMENTO - changes the slide time between played notes.
(16) VOLUME - controls the output level of the synthesizer.
(17) OCTAVE UP/DOWN - raise or lower the keyboard’s pitch range in
steps of an octave.
(18) PITCH BEND WHEEL - this spring loaded wheel allows you to lower / raise
the pitch expressively.
(19) MOD WHEEL - used for expressive modulation of parameters.
(20) KEYS - 49 semi-weighted full-size keys featuring expressive velocity and
after-touch.
