32 PROTON User Manual
19. MIDI CCs
The Proton responds to two MIDI CCs:
Modulation Wheel (MIDI CC #1 (MSB) and CC #33 (LSB)) which can also be assigned to the Assign Out using the Synthtribe App;
Sustain Pedal (MIDI CC #64).
20. SysEx
The Proton can be controlled using the System Exclusive protocol. The format of Proton SysEx messages is as follows:
Lead Manufacturer ID Model ID Dev PKT SPKT SSPKT Value End
F0 00 20 32 00 01 25 00 0x74 0x10 F7
The following table shows the SSPKT numbers and their associated values
SSPKT Function Value Range Default Value Description
0x0F Polychain enable/disable 0-1 0
0 = disabled;
1 = enabled
0x10 Dipswitch enable/disable 0-1 0
0 = dipswitch MIDI channel;
1 = software MIDI channel
0x11 Software MIDI Channel 0-15 0
0x13 Mono key priority 0-2 2 0 = low; 1 = high; 2 = last
0x14 Paraphonic key priority 0-2 2 0 = low; 1 = high; 2 = last
0X17 Assign out 1 0-4 0
0 = Osc 1 CV;
1 = Osc 2 CV;
2 = velocity;
3 = mod wheel;
4 = aftertouch
0x18 Assign out 2 0-4 0
0 = Osc 1 CV;
1 = Osc 2 CV;
2 = velocity;
3 = mod wheel;
4 = aftertouch
0x19 Minimum MIDI note 0C – 60 0C 0C = MIDI C0
0x1A Maximum MIDI note 0C – 60 60 60 = MIDI C7
0x1B Mute out of range notes 0-1 0
0 = disabled;
1 = mute out of range notes
0x1D Forward clock 0-1 1
0 = disabled;
1 = enabled
0x1E Assign in destination 0-6 0
0 = none;
1 = Osc 1;
2 = Osc 2;
3 = Osc 1&2;
4 = VCF 1;
5 = VCF 2;
6 = VCF 1&2
0x1F Assign in depth 0-65 65
0x21 Local control on/o 0-1 1
0 = second panel enabled;
1 = second panel disabled
0x23 VCF link 0-2 0
0 = no link;
1 = mod link;
2 = inverse mod link
0x24 VCF soft 0-3 0
0 = disabled;
1 = VCF1 enabled;
2 = VCF2 enabled;
3 = both enabled
0x25 VCF Key tracking 0-3 0
0 = disabled;
1 = VCF1 enabled;
2 = VCF2 enabled;
3 = both enabled
