BEIER-Electronic SFR-1-D - Functions of the SFR-1-D

GB Double Sound Speed Controller SFR-1-D
24 BEIER-Electronic 01.03.2020
sounds for motion starting, driving, and motion stopping are necessary because
there are no idle and engine start/stop sounds when turning a tank turret.
The speed for engine sound 2, can be controlled with one of the 8 proportional
channels #1 - #8. Which channel, can be set in the Sound-Teacher (see page 63).
There are 2 options to activate/deactivate engine sound 2:
• by selecting the function "Engine Sound 2 on/off" for a position in “Configuration” -
“Proportional channels”, “Nautic 1”, Nautic 2”, or “EKMFA mode”
• by using the option "Turn on sound automatically by motion" in “Configuration” -
“Engine Sound 2”.
Furthermore, there is also the option when starting engine sound 2, to shut off the
normal engine sound automatically - and vice versa. Thus it is easy possible to
change between two different engine sounds.
However, functions as reversing sound/light or brake sound/light are not directly
controlled by driving sound 2. These functions continue to be controlled through the
throttle channel at the normal engine sound.
Functions of the SFR-1-D
Additionally to the driving sound, the SFR-1-D offers more features, which can be
controlled by the remote control.
Overview of all the functions:
Additional sounds
• Trigger additional sounds 1 - 30
Outputs / Lighting
functions
• Switching the outputs 1 - 16
• Output sequence 1 - 8
• Light switch +/-
• Parking light
• Low beam headlight
• High beam headlight / headlight flasher
• Front fog light
• Rear fog light
• Indicator left
• Indicator right
• Hazard lights
• Driving Backwards
• Brake light
• Locomotive: Driving light
• Ship: At anchor
• Ship: In operation
• Ship: Aground
• Ship: Restricted in ability to manoeuvre
• Ship: Unable to manoeuvre
