GB Double Sound Speed Controller SFR-1-D
01.03.2020 BEIER-Electronic 33
One-channel multi-function selection (EKMFA)
To use the EKMFA mode it must be activated in the Sound-Teacher.
With the “One-channel multi-function selection” (EKMFA) you can control up to 30
functions of the SFR-1-D with only one proportional channel (channel #3).
You can assign in the Sound-Teacher the functions you would like to trigger with the
EKMFA-mode (see page 68).
To trigger a particular sound or function, the transmitter switch or joy-stick must be
moved from position N to position A or D for a certain number.
The last „function“ is always stored, enabling you to repeat the last sound or the last
function as many times as you wish, without counting once more. Simply hold the
joy-stick for one second in the position B, or C to repeat the last sound.
In order to switch the 16 outputs directly, they must be configured in the Sound-
Teacher as “static“, “flashing“ or “pulse“. An output that is configured e.g. as
reversing or brake light, cannot be switched on.
Nautic mode / multiswitch mode
To use the nautic/multiswitch mode it must be activated in the Sound-Teacher under
„Nautic 1“ or ”Nautic 2“.
The nautic/multiswitch mode is probably the most convenient method of operating
the SFR-1-D.
The SFR-1-D supports following switch modules (and modules compatible with
them):
• BEIER-Electronic NMS-16-R, NMS-16-G and NMS-24-G
• BEIER-Electronic EMS-16-R, EMS-16-G and EMS-24-G
• BEIER-Electronic MSC-8-C, MSC-10-C and MSC-8-C-LCD
• Graupner Nautic-Expert Modul (Nr. 4108) and Multikanal
• Robbe Multi-Switch Module (Nr. 8084, 8101, 8413, F1511)
• Mergen/CP 12-Kanal and 16-Kanal Multiswitch
You can install up to two switch modules in your transmitter to control functions. With
available space they can be built directly into the remote control or into an external
housing (available in our shop).
Proportional channel #5 (X2/5) and/or channel #6 (X2/6) are connected to the
receiver channel with servo patch cables.
