BEIER-Electronic SFR-1-D - Technical details

GB Double Sound Speed Controller SFR-1-D
6 BEIER-Electronic 01.03.2020
Technical details
Supply Voltage (U
b
):
6 – 18 V DC
Power consumption:
Bias current: approx. 1 mA
Standby current (sound, motor and outputs off):
approx. 80 mA
Motor current (M1 and M2):
Max. 2 x 30 A continuous current,
60 A short-term current (1 minute)
Motor current (M3 and M4):
Max. 2 x 2 A continuous current,
3 A short-term current (10 seconds)
BEC voltage:
approx. 5,6 V
BEC current:
max. 3 A continuous current,
5 A short term (10 seconds)
Proportional inputs:
8 inputs
Supported protocols:
• PPM / PCM (1,000 - 2,000 ms)
• Sum signals: S-Bus, SUMD/SUMD3 and
i-Bus (max. 16 channels)
•
Nautic / Multiswitch / Multikanal / EMS
Servo outputs:
4 outputs (1,000 - 2,000 ms)
Switching outputs:
16 outputs (npn – open collector),
max. 1,5 A each output, the total current of all
outputs must not exceed 3,0 A
Output smoke generator:
Max. 3 A
Output BB gun:
Max. 3 A
Audio amplifier:
20 W
Recommended loudspeaker:
4 – 8 Ω
Volume setting:
With extra poti (100 kΩ) and/or by the radio
Memory for sound files:
Micro SD card (1 to 32 GB)
May. length of sound:
approx. 180 minutes per 1 GB
Supported file format:
WAV-Format, 8/16 Bit, Mono/Stereo, 22/44 kHz
Sound output:
16 Bit, Mono, 22/44 kHz
Number of possible sounds:
• 5 running steps/gears (internally in up to 255
steps accelerated)
• 8 change sounds between the running
steps/gears
• Turn on noise, turn off noise, starting noise,
stopping noise, idling noise, brake noise,
reverse warning, curve squeal, flashing lights
sound
• 30 additional sounds
• 8 random sounds (random generator)
• 30 tracks for WAV-Player
Random sound generator:
Times between 1 to 999s adjustable
Additional ports:
• Programming interface for data cable
