GB Double Sound Speed Controller SFR-1-D
01.03.2020 BEIER-Electronic 39
Outputs "Bending light left" and "Bending light right"
These outputs can be turned on at cornering. There are 2 ways in which the bending
lights can be turned on:
1. By steering on proportional channel #2 (X2/2)
2. By the indicator signal
3. By driving backwards
For more information about these two options, please look on the page 72. The
bending lights can optionally also be front fog lights and can then also be switched
by the function "Front fog light". The switching on and off of the bending lights is not
immediate, but with a dimming function.
Output „Combined headlight“
Using the combined headlight, “parking light“, “low beam headlight“ and “high
beam headlight“ can be switched using just one output.
The Intensity for each of the 3 lights can be adjusted seperately:
The intensity of the parking light is entered under “intensity“(e.g. 10 %).
The intensity of the low beam headlight is entered under “Option 1“(e.g. 30 %).
The intensity of the high beam headlight is entered under “Option 2“(z.B. 60 %).
However, it should be noted that these 3 intensities are added, if more than one light
is switched on. Summing up, you should avoid a value that is over 100 %.
Output “Combined back light“
Using the combined rearlight, “parking light“, “brake light“ and “rear fog light“
can be switched using just one output.
The Intensity for each of the three lights can be adjusted seperately:
The intensity of the parking light is entered under “Intensity“(e.g. 10 %).
The intensity of the brake light is entered under “Option 1“(e.g. 30 %).
The intensity of the rear fog light is entered under “Option 2“(z.B. 60 %).
However, it should be noted that these three intensities are added, if more than one
light is switched on. Summing up, you should avoid a value that is over 100 %.
Output „Combined American rear light left/right“
This setting switches three light functions, namely „parking light“, “brake light” and
“indicator right” respectively “indicator left” via only one output.
For each of this light functions you can set the intensity separately.
The intensity for “Parking light” is set at “Intensity” for example 10 %.
The intensity for “Brake light” is set at “Option 1” for example 100 %.
The intensity for “Indicator light” is set at “Option 2” for example 50 %.
In contrast to other combined lights, the intensities are not summarised!
Output „Locomotive – driving light forward/backward“
These two output types are triggered via the function "Locomotive - Driving light”. If
the locomotive is moving forwards, the output "Locomotive - Driving light forward" is
activated. If the locomotive runs backwards, the output "Locomotive - Driving light
