Output „Temperature controlled“
If the motor output stage requires some cooling with an additional fan, the fan can be
controlled via the existing temperature sensor. In Configuration  Outputs 
Outputs you can define from which temperature the fan should be switched on
("Option 2") and at which temperature the fan should be switched off again ("Option
1").
Navigation lights for ships
With these outputs the lights of ships can be authentically simulated. The lights are
controlled using this logic-table:
Output
All
-round light red top
All
-round light red middle
All
-round light red bottom
All
-round light green top
All
-round light white
middle
All
-round light white
bottom
1. Masthead light
2. Masthead light
Anchor light
Side light
Stern light
Towing light
Function
At anchor

Aground



In operation



Restricted in ability to
manoeuvre






Unable to manoeuvre




Constrained by draught






Towing





Assisting




Fishing





 = output is active
 = output is only active, if the ship is in operation
This table is fixed stored in the firmware and can not be changed!
Example:
If the function “In operation“ is active, the outputs which are configured as “1.
Masthead“, “Side light“ and “Stern light“ are switched on.
If you want to use light functions, the outputs must be configured (which light is
connected to which output) and secondly the functions must be allocated to the
control elements (e.g. nautic switch) of the transmitter. You should use “Memory“
functions for this.
Some of the available functions are mutually exlusive. For example, a ship cannot be
“At anchor“ and be “In operation“ at the same time.
The relationship between light functions and outputs (see table), are fixed and can
not be changed!
