This can be used to generate very impressive light effects, such as a simulation of
fire or a welding torch.
The Sound-Teacher allows you to adjust the sensitivity of the flicker effect separately
for each of the outputs. A value between 1 and 255 can be entered in the field
“Option 1“.The higher the value the higher the sound volume must be to activate
the flicker effect.
Output „Daytime running light“
The output for the daytime running light will be switched on, if the parking light and
the low beam headlight are not switched on. When the parking light or low beam
headlight are turned on, the brightness changes to the value of "Option 1". If this
value is 0, the daytime running light is switched off when the parking light or low
beam headlight are switched on. When the indicators are activated, the brightness of
the daytime running light is switched to the value of "Option 2".
“Parking light“, “Low beam headlight“, “High beam headlight“, “Front fog
light“ and “Rear fog light“ outputs
The outputs for these lights are switched on as soon as the corresponding function is
switched on. The function can be switched on using a proportional channel, a nautic
switch or the EKMFA-mode.
Of course, you do not have to keep to this order. That means for example if you don’t
need a rear fog light, you can connect something else to the output.
The lights can be switches with the programmable light switch under "Configuration",
"Outputs" and "Light switch" (see page 83).
Output “Reversing light”
The output for the reverse driving light is always switched on when the vehicle runs
backwards.
If the reversing light is to be switched via an existing switching output of a speed
controller, the switching output of the speed controller is connected directly to a
switching input (X1/3 - X1/6) of the sound module and the switching input is assigned
the "Drive backwards" function. Here the reversing light (and the reversing warning)
is no longer switched via the internal evaluation of the direction of travel, but via this
switching input.
Output “Brake light“
The brake light is always shortly turned on when the driving speed is reduced
substantial. The sensitiveness can be configured in the Sound-Teacher (see page
81).
If the brake light is to be switched via an existing switching output of a speed
controller, the switching output of the speed controller is connected directly to a
switching input (X1/3 - X1/6) of the sound module and this switching input is
assigned the "Brake light" function. Here the brake light is no longer switched via the
internal evaluation of the driving speed, but via the switching input.
