GB Sound module USM-RC-3
72 BEIER-Electronic 11.10.2021
Configuration - Engine Sound - Engine Sound 2
Different parameters for engine sound 2 can be configured in this section.
Speed via proportional channels:
Here it is determined by which proportional channel the speed of the 2nd engine
sound is to be controlled.
Zero point:
The neutral position of the throttle stick can be set between 1.00 - 2.00 ms. Most
transmitter and speed controller have its zero point at 1.50 ms.
Zero point deadband:
For the throttle control an area can be defined with this deadband, where the
stationary sound for engine sound 2 should be played. This area ranges between 1
and 30.
Maximum sound speed:
The sound speed at full power can be set between 60% and 300%.
Activate the option "When starting engine sound 1 or 2, turn off the other", when you
never want to use both engine sounds at the same time. If you are runnig your model
with engine sound 1 and you activate engine sound 2, the first engine sound is
automatically turned off. If the first engine sound is activated again, the second
engine sound goes off automatically.
Additionally you can choose whether changing sounds between the two engine
sounds, like starting and stopping sounds should be played.
With the option "Turn on engine sound automatically by motion" it can be
determined, that the second driving sound automatically turns on as soon as the
throttle control for the engine sound 2 is out of neutral position. This is useful, for
example, if you want to realize a tank turret rotation. Otherwise, you need to activate
engine sound 2 first with the function “Engine sound 2 on/off”.
