17
P-13 Operating Mode Select 0 2 0 -
Provides a quick set up to configure key parameters according to the intended application of the drive. Parameters are preset
according to the table.
0: Industrial Mode. Intended for general purpose applications.
1: Pump Mode. Intended for centrifugal pump applications.
2: Fan Mode. Intended for Fan applications.
Setting Application Current Limit (P-54) Torque Characteristic (P-28 & P-29) Spin Start (P-33)
0 General 150% Constant 0 : Off
1 Pump 110% Variable 0 : Off
2 Fan 110% Variable 2 : On
P-14 Extended Menu Access code 0 65535 0 -
Enables access to Extended and Advanced Parameter Groups. This parameter must be set to the value programmed in P-37 (default:
101) to view and adjust Extended Parameters and value of P-37 + 100 to view and adjust Advanced Parameters. The code may be
changed by the user in P-37 if desired.
6.2. Extended Parameters
Par. Description Minimum Maximum Default Units
P-15 Digital Input Function Select 0 17 0 -
Defines the function of the digital inputs depending on the control mode setting in P-12. See section 8,Analog and Digital Input
Configurations for more information.
P-16 Analog Input 1 Signal Format See Below
U 0-10
U 0-10U 0-10
U 0-10
-
U 0-10
U 0-10U 0-10
U 0-10 = 0 to 10 Volt Signal (Uni-polar). The drive will remain at 0.0Hz if the analog reference after scaling and offset are applied is
=<0.0%
b 0-10
b 0-10b 0-10
b 0-10 = 0 to 10 Volt Signal, bi-directional operation. The drive will operate the motor in the reverse direction of rotation if the
analog reference after scaling and offset are applied is <0.0%. E.g. for bidirectional control from a 0 – 10 volt signal, set P-35 =
200.0%, P-39 = 50.0%
A 0-20
A 0-20A 0-20
A 0-20 = 0 to 20mA Signal
t 4-20
t 4-20t 4-20
t 4-20 = 4 to 20mA Signal, the BFI will trip and show the fault code 4-20F
4-20F4-20F
4-20F if the signal level falls below 3mA
r 4-20
r 4-20r 4-20
r 4-20 = 4 to 20mA Signal, the BFI will run at Preset Speed 1 (P-20) if the signal level falls below 3mA
t 20-4
t 20-4t 20-4
t 20-4 = 20 to 4mA Signal, the BFI will trip and show the fault code 4-20F
4-20F4-20F
4-20F if the signal level falls below 3mA
r 20-4
r 20-4r 20-4
r 20-4 = 20 to 4mA Signal, the BFI will run at Preset Speed 1 (P-20) if the signal level falls below 3mA
U 10-0
U 10-0U 10-0
U 10-0 = 10 to 0 Volt Signal (Uni-polar). The drive will operate at Maximum Frequency / Speed if the analog reference after scaling
and offset are applied is =<0.0%
P-17 Maximum Effective Switching Frequency 4 32 8 kHz
Sets maximum effective switching frequency of the drive. If “rEd” is displayed, the switching frequency has been reduced to the
level in P0-32 due to excessive drive heatsink temperature.
P-18 Output Relay Function Select 0 9 1 -
Selects the function assigned to the relay output. The relay has two output terminals, Logic 1 indicates the relay is active, and
therefore terminals 10 and 11 will be linked together.
0: Drive Enabled (Running). Logic 1 when the motor is enabled
1: Drive Healthy. Logic 1 when power is applied to the drive and no fault exists
2: At Target Frequency (Speed). Logic 1 when the output frequency matches the setpoint frequency
3: Drive Tripped. Logic 1 when the drive is in a fault condition
4: Output Frequency >= Limit. Logic 1 when the output frequency exceeds the adjustable limit set in P-19
5: Output Current >= Limit. Logic 1 when the motor current exceeds the adjustable limit set in P-19
6: Output Frequency < Limit. Logic 1 when the output frequency is below the adjustable limit set in P-19
7: Output Current < Limit. Logic 1 when the motor current is below the adjustable limit set in P-19
8 : Analog Input 2 > Limit. Logic 1 when the signal applied to analog input 2 exceeds the adjustable limit set in P-19
9 : Drive Ready to Run. Logic 1 when the drive is ready to run, no trip present.
P-19 Relay Threshold Level 0.0 200.0 100.0 %
Adjustable threshold level used in conjunction with settings 4 to 7 of P-18
P-20 Preset Frequency / Speed 1 -P-01 P-01 5.0 Hz /
Rpm
P-21 Preset Frequency / Speed 2 -P-01 P-01 25.0 Hz /
Rpm
P-22 Preset Frequency / Speed 3 -P-01 P-01 40.0 Hz /
Rpm
P-23 Preset Frequency / Speed 4 -P-01 P-01 P-09 Hz /
Rpm
Preset Speeds / Frequencies selected by digital inputs depending on the setting of P-15
If P-10 = 0, the values are entered as Hz. If P-10 > 0, the values are entered as Rpm.
Note Changing the value of P-09 will reset all values to factory default settings
P-24 2nd Deceleration Ramp Time (Fast Stop) 0.00 600.0 0.00 s
This parameter allows a 2
nd
ramp time to be programmed into the drive.
This ramp time is automatically selected in the case of a mains power loss if P-05 = 2 or 3. When set to 0.00, the drive will coast to
stop.
When using a setting of P-15 that provides a “Fast Stop” function, this ramp time is also used.
