1.2.
Quick Start Process
Step Action See Section Page
1 Identify the Enclosure Type, Model Type and ratings of
your drive from the model code on the label. In particular
- Check the voltage rating suits the incoming supply
- Check the output current capacity meets or exceeds
the full load current for the intended motor
2.1 Identifying the Drive by Model Number 7
2 Unpack and check the drive. Notify the supplier and
shipper immediately of any damage.
3 Ensure correct ambient and environmental conditions for
the drive are met by the proposed mounting location.
9.1 Environmental 28
4 Install the drive in a suitable cabinet (IP20 Units), ensuring
suitable cooling air is available. Mount the drive to the
wall or machine (IP66).
3.1
3.3
3.4
3.5
3.6
General
Mechanical Dimensions and Mounting – IP20 Open Units
Guidelines for Enclosure Mounting – IP20 Units
Mechanical Dimensions – IP66 Enclosed Units
Guidelines for Mounting Enclosed Units
8
8
8
9
9
5 Select the correct power and motor cables according to
local wiring regulations or code, noting the maximum
permissible sizes
9.2 Rating Tables 28
6 If the supply type is IT or corner grounded, disconnect the
EMC filter before connecting the supply.
9.5 EMC Filter Disconnect 29
7 Check the supply cable and motor cable for faults or short
circuits.
8 Route the cables
9 Check that the intended motor is suitable for use, noting
any precautions recommended by the supplier or
manufacturer.
4.10 EMC Compliant Installation 14
10 Check the motor terminal box for correct Star or Delta
configuration where applicable
4.5 Motor Terminal Box Connections 12
11 Ensure suitable wiring protection is providing, by installing
a suitable circuit breaker or fuses in the incoming supply
line
4.3.2
9.2
Fuse / Circuit Breaker Selection
Rating Tables
12
28
12 Connect the power cables, especially ensuring the
protective earth connection is made
4.1
4.2
4.3
4.4
Connection Diagram
Protective Earth (PE) Connection
Incoming Power Connection
Motor Connection
11
11
12
12
13 Connect the control cables as required for the application 4.6
4.10
7
7.11
Control Terminal Wiring
EMC Compliant Installation
Analog and Digital Input Macro Configurations
Example Connection Diagrams
13
14
23
26
14 Thoroughly check the installation and wiring
15 Commission the drive parameters 5.1
6
Managing the Keypad
Parameters
15
16
