2. General Information and Ratings
2.1. Identifying the Drive by Model Number
Each drive can be identified by its model number, as shown in the table below. The model number is on the shipping label and the drive
nameplate. The model number includes the drive and any options.
BFI - 3 - 1 2 - 0023 - 1 F 1 X
Product Family IP Rating 2 = IP20
X = IP66 Non Switched
Y = IP66 Main switch, Hand control and
potentiometer
Generation
Frame Size 1-3 Dynamic Brake
Transistor
1 = Not Fitted
4 = Internal Transistor
Input Voltage 1 = 110 – 115 V
2 = 200 – 240 V
4 = 380 – 480 V
EMC-filter Type 0 = No internal filter
F = Internal filter
Current Rating
e.g. 0023 = 2.3A
No. Of Input Phases 1 = Single Phase Input
3 = 3 Phase Input
2.2. Drive Model Numbers
110-115V ±10% - 1 Phase Input - 3 Phase 230V Output (Voltage Doubler), Built-in-EMC-filter
Model Number kW Output Current (A) Frame Size
BFI-E3-11-0023-101# 0.37 2.3 1
BFI-E3-11-0043-101# 0.75 4.3 1
BFI-E3-21-0058-104# 1.1 5.8 2
200-240V ±10% - 1 Phase Input - 1 Phase Output IP20/IP66, Built-in-EMC-filter
Model Number kW Output Current (A) Frame Size
BFI-E3-12-0043-1F1#-01 0.37 4.3 1
BFI-E3-12-0070-1F1#-01 0.75 7,0 1
BFI-E3-12-0105-1F4#-01 1.1 10,5 1
200-240V ±10% - 1 Phase Input - 3 Phase Output IP20/IP66, Built-in-EMC-filter
Model Number kW Output Current (A) Frame Size
BFI-E3-12-0023-1F1# 0.37 2.3 1
BFI-E3-12-0043-1F1# 0.75 4.3 1
BFI-E3-12-0070-1F1# 1.5 7 1
BFI-E3-22-0070-1F4# 1.5 7 2
BFI-E3-22-0105-1F4# 2.2 10.5 2
200-240V ±10% - 3 Phase Input - 3 Phase Output IP20/IP66, Built-in-EMC-filter
Model Number kW Output Current (A) Frame Size
BFI-E3-22-0070-3F4# 1.5 7 2
BFI-E3-22-0105-3F4# 2.2 10.5 2
BFI-E3-32-0180-3F4# 4.0 18 3
BFI-E3-32-0240-3F4# 5.5 24 3
BFI-E3-42-0300-3F4# 7,5 30 4
BFI-E3-42-0460-3F4# 11 46 4
380-480V ±10% - 3 Phase Input - 3 Phase Output IP20/IP66, Built-in-EMC-filter
Model Number kW Output Current (A) Frame Size
BFI-E3-14-0022-3F1# 0.75 2.2 1
BFI-E3-14-0041-3F1# 1.5 4.1 1
BFI-E3-24-0041-3F4# 1.5 4.1 2
BFI-E3-24-0058-3F4# 2.2 5.8 2
BFI-E3-24-0095-3F4# 4 9.5 2
BFI-E3-34-0140-3F4# 5.5 14 3
BFI-E3-34-0180-3F4# 7.5 18 3
BFI-E3-34-0240-3F42 11 24 3
BFI-E3-44-0300-3F42 15 30 4
BFI-E3-44-0390-3F42 18,5 39 4
BFI-E3-44-0460-3F42 22 46 4
NOTE
For IP20 units, replace ‘#’ with ‘2’
For IP66 Non Switched Units, replace ‘#’ with ‘X’, For IP66 Switched Units, replace ‘#’ with ‘Y’
