Beijer Electronics E3 - 9 Technical Data; Environmental; Rating Tables

28
9. Technical Data
9.1. Environmental
Operational ambient temperature range
Open Drives: -10 … 50°C (frost and condensation free)
Enclosed Drives: -10 ... 40°C (frost and condensation free)
Storage ambient temperature range: -40 … 60°C
Maximum altitude: 2000m. Derate above 1000m : 1% / 100m
Maximum humidity: 95%, non-condensing
NOTE For UL compliance: the average ambient temperature over a 24 hour period for 200-240V, 2.2kW and 3HP, IP20 drives is 45°C.
9.2. Rating Tables
110 - 115 Volt (+ / - 10%) 1 Phase Input, 3 Phase 230V Output
Frame
size
Power
rating
Nominal Fuse Supply Nominal Motor Maximum Recommended
Input Or Cable Output Cable Motor Brake
Current MCB (Type B) Size Current Size Cable Resistance
[kW] [A] Non UL UL [mm2] AWG / kcmil [A] [mm2] AWG / kcmil Length [m] Ω
1 0.37
7.8
10 10 2.5 14 2.3 1.5 14 100 -
1 0.75
15.8
25 20 4 10 4.3 1.5 14 100 -
2 1.1
21.9
32 30 6 8 5.8 1.5 14 100 100
200 - 240 Volt (+ / - 10%) 1 Phase Input, 3 Phase Output
Frame
size
Power
rating
Nominal Fuse Supply Nominal Motor Maximum Recommended
Input Or Cable Output Cable Motor Brake
Current MCB (Type B) Size Current Size Cable Resistance
[kW] [A] Non UL UL [mm2] AWG / kcmil [A] [mm2] AWG / kcmil Length [m] Ω
1 0.37 3,7 10 6 1.5 14 2.3 1.5 14 100 -
1 0.75 7,5 10 10 1.5 14 4.3 1.5 14 100 -
1 1.5 12.9 16 17,5 2.5 12 7 1.5 14 100 -
2 1.5 12.9 16 17,5 2.5 12 7 1.5 14 100 100
2 2.2 19.2 25 25 4 10 10.5 1.5 14 100 50
200 - 240 Volt (+ / - 10%) 3 Phase Input, 3 Phase Output
Frame
size
Power
rating
Nominal Fuse Supply Nominal Motor Maximum Recommended
Input Or Cable Output Cable Motor Brake
Current MCB (Type B) Size Current Size Cable Resistance
[kW] [A] Non UL UL [mm2] AWG / kcmil [A] [mm2] AWG / kcmil Length [m] Ω
1 0.37 3.4 6 6 1.5 14 2.3 1.5 14 100 -
1 0.75 5,6 10 10 1.5 14 4.3 1.5 14 100 -
1 1.5 9,5 16 15 1.5 14 7 1.5 14 100 -
2 1.5 9,5 16 15 1.5 14 7 1.5 14 100 100
2 2.2 12,1 16 17,5 2.5 12 10.5 1.5 14 100 50
3 4 20,9 25 30 4 10 18 2.5 10 100 25
3 5.5 26,4 32 35 6 10 24 4 10 100 20
4 7.5 33,3 40 45 16 8 30 6 8 100 15
4 11 50,1 63 70 25 4 46 10 6 100 10
380 - 480 Volt (+ / - 10%) 3 Phase Input, 3 Phase Output
Frame
size
Power
rating
Nominal Fuse Supply Nominal Motor Maximum Recommended
Input Or Cable Output Cable Motor Brake
Current MCB (Type B) Size Current Size Cable Resistance
[kW] [A] Non UL UL [mm2] AWG / kcmil [A] [mm2] AWG / kcmil Length [m] Ω
1 0.75 3,5 6 6 1.5 14 2.2 1.5 14 100 -
1 1.5 5,6 10 10 1.5 14 4.1 1.5 14 100 -
2 1.5 5,6 10 10 1.5 14 4.1 1.5 14 100 250
2 2.2 7,5 10 10 1.5 14 5.8 1.5 14 100 200
2 4 11,5 16 15 2.5 12 9.5 1.5 14 100 120
3 5.5 17,2 25 25 4 10 14 1.5 12 100 100
3 7.5 21,2 25 30 4 10 18 2.5 10 100 80
3 11 27,5 32 35 6 8 24 4 10 100 50
4
15 34.2
50 45 16 8 30 6 8 100 30
4
18.5 44.1
50 60 16 8 39 10 8 100 22
4
22 51.9
63 70 25 6 46 16 6 100 22
9.3. Single Phase Operation of Three Phase Drives
All drive models intended for operation from three phase mains power supply (e.g. model codes BFI-E3-xxxxxx-3xxx) may be
operated from a single phase supply at up to 50% of maximum rated output current capacity.
In this case, the AC power supply should be connected to L1 (L) and L2 (N) power connection terminals only.
