Communication is working but BFI-E3…-MTP doesn’t run the motor correct:
- Software enable bridge between terminal 1 and 2 in place?
- BFI-E3…-MTP is powered up?
- No alarm in BFI-E3…-MTP?
- Parameter P-12 set to 3 or 4 in BFI-E3…-MTP?
- Variable Ready to Run must be 1 to run the BFI-E3
- Stop in display?
o Start signal by bus is missing. As soon as BFI receives a start signal a value
between 0 and Maximum speed is displayed instead of Stop.
- H 0.0 in display?
Start signal arrived but no speed setpoint
o Speed sent to BFI-E3 must be a value between parameter value P1-01 and P1-02.
o Speed into Function block is a REAL. Value 50.0 Hz means value 500 being sent
to BFI-E3
o Check that sent speed by bus corresponds with value in P0-03 in BFI-E3.
