Installation OCTOPUS OS3
Release
03
08/2020
17
26 ... 27 Supply voltage BB 2 voltage inputs for redundant power supply
Rated voltage 24 V DC
Rated voltage range 16.8 V DC ... 32 V DC
Connection type 5-pin M12 connector
HH 2 voltage inputs for redundant power supply
Rated voltage 36 V DC ... 48 V DC
Rated voltage range 25.2 V DC ... 60 V DC
Connection type 5-pin M12 connector
PP 2 voltage inputs for redundant power supply
PoE
Rated voltage
48 V DC
PoE+
Rated voltage
54 V DC
Connection type 5-pin M12 connector
QQ 2 voltage inputs for redundant power supply
Rated voltage 24/36/48 V DC
Rated voltage range 16.8 V DC ... 60 V DC
Connection type 5-pin M12 connector
M9 Rated voltage 110 V AC ... 230 V AC,
50 Hz ... 60 Hz
Rated voltage range 88 V AC ... 265 V AC,
47 Hz ... 63 Hz
Connection type 5-pin M12 connector
N9 Rated voltage 72 V DC ... 110 V DC
Rated voltage range 50.4 V DC ... 138 V DC
Connection type 5-pin M12 connector
28 ... 29 Certificates and
declarations
Z9 CE, FCC, EN 61131, EN 62368-1
Y9 Z9 + cUL 61010
S9 Z9 + EN 50121-4 + EN 50155
30 ... 31 Software packages 99 Reserved
UR Unicast Routing
MR Unicast + Multicast Routing
32 ... 33 Customer-specific
version
HH Hirschmann standard
34 Hardware
configuration
S Standard
35 Software
configuration
E Entry (Hirschmann Standard)
B Diagnostic User (BDEW)
I Ethernet/IP
P PROFINET/IO
36 ... 37 Software level 2A HiOS Layer 2 Advanced
3A HiOS Layer 3 Advanced
38 ... 42 Software version 08.0. Software version 08.0.
XX.X Current software version
43 ... 44 Maintenance
version
00 Maintenance version 00
XX Current maintenance version
Item Characteristic Characteri
stic value
Description
Table 1: Device name and product code
