9 Immunity
Immunity Standard applications
a
a. EN 61131-2, CE, FCC – applies to all devices
Railway applications (trackside)
b
b. According to EN 50121-4.
Railway applications (on vehicles)
c
c. According to EN 50155.
IEC 60068-2-6, test Fc Vibration 5 Hz ... 8.4 Hz with 0.14 in
(3.5 mm) amplitude
— Operating
5 Hz ... 150 Hz,
Broadband noise
vertical: 1.0 m/s² (rms)
horizontal: 0.7 m/s² (rms)
8.4 Hz ... 200 Hz with 1 g — disabled:
5 Hz ... 150 Hz,
Broadband noise
vertically: 5.72 m/s² (rms)
horizontally: 3.96 m/s² (rms)
IEC 60068-2-27, test Ea Shock 15 g at 11 ms — vertical: 30 m/s², 30 ms
horizontal: 50 m/s², 30 ms
Table 29: Immunity
