7 Technical data
7.1 General data
7.2 Supply voltage
OCTOPUS OS3
Dimensions
W × H × D
See “Dimension drawings” on page 50.
Weight
(values vary depending
on characteristic value of
the supply voltage)
Device variants with 8 × Ethernet ports 11.7 lbs ... 12.4 lbs
(5.3 kg ... 5.6 kg)
OS3-..-......0008...
Device variants with 16 × Ethernet ports 13.9 lbs ... 15.0 lbs
(6.3 kg ... 6.8 kg)
OS3-..-......0808...
OS3-..-......0016...
Device variants with 24 × Ethernet ports 16.1 lbs ... 17.6 lbs
(7.3 kg ... 8.0 kg)
OS3-..-......0816...
OS3-..-......1608...
OS3-..-......0024...
Mounting See “Mounting on a flat surface” on page 35.
Pollution degree 2
Degree of protection IP65/67
Table 16: General data: OCTOPUS OS3
Supply voltage with the characteristic value BB
Rated voltage 24 V DC
Voltage range including maximum
tolerances
16.8 V DC ... 32 V DC
Connection type 5-pin, “L”-coded M12 plug
Tightening torque 5.3 lb-in (0.6 Nm)
Wire diameter AWG16 (1.5 mm²)
a
a. When using the supplied plug.
Power loss buffer >20 ms
Overload current protection on the device Non-replaceable fuse
Back-up fuse for each voltage input Nominal rating: max. 20 A
Characteristic: slow blow
Peak inrush current 1.5 A
Connection for functional ground See “Grounding the device” on page 36.
Current integral I²t <0.2 A²s
Table 17: Supply voltage with characteristic value BB
