48
Installation OCTOPUS OS3
Release
03
08/2020
7.3 Power consumption/power output
Note: The values for the maximum power output and the maximum power
consumption in table 24 apply to the fully expanded devices. See the type
plate of the device for the specifications of your device.
Current integral I²t non-PoE <1.5 A²s
PoE <1 A²s
Max. PoE power Nominally 60 W
a. When using the supplied plug.
Ground connection
Ground connection See “Grounding the device” on page 36.
Connection type M4 screw
Tightening torque min. 0.5 Nm
max. 1.0 Nm
min. conductor
diameter
The cross-section of the protective
conductor is the same size as or bigger
than the cross-section of the power supply
cables.
Table 23: Ground connection
Device name Supply voltage
variants
Maximum power
consumption
Maximum power
output
OS3-30.....16... (16 ports) all variants 24 W 80 Btu (IT)/h
OS3-30.....24... (24 ports) all variants 30 W 103 Btu (IT)/h
OS3-40.....08... (8 ports) all variants 20 W 67 Btu (IT)/h
OS3-40.....16... (16 ports) all variants 26 W 88 Btu (IT)/h
OS3-40.....24... (24 Ports) all variants 32 W 111 Btu (IT)/h
OS3-34.....16... (16 ports) PP 155 W 83 Btu (IT)/h
OS3-34.....16... (16 ports) M9, N9, QQ 100 W 118 Btu (IT)/h
OS3-34.....24... (24 ports) PP 160 W 102 Btu (IT)/h
OS3-34.....24... (24 ports) M9, N9, QQ 106 W 138 Btu (IT)/h
OS3-44.....08... (8 ports) PP 149 W 65 Btu (IT)/h
OS3-44.....08... (8 ports) M9, N9, QQ 94 W 99 Btu (IT)/h
OS3-44.....16... (16 ports) PP 156 W 87 Btu (IT)/h
OS3-44.....16... (16 ports) M9, N9, QQ 101 W 122 Btu (IT)/h
OS3-44.....24... (24 ports) PP 162 W 109 Btu (IT)/h
OS3-44.....24... (24 ports) M9, N9, QQ 108 W 146 Btu (IT)/h
OCTOPUS 24GE-HV-Trainrouter 32 W 110 Btu (IT)/h
Table 24: Power consumption/power output
Supply voltage with the characteristic value N9
Table 22: Supply voltage with characteristic value N9
