38
Installation OCTOPUS OS3
Release
03
08/2020
2.4 Connecting the supply voltage
Mount the power supply cable to the power supply connector of the
device.
You find the prescribed tightening torque in chapter:
“General data” on page 45
Enable the supply voltage.
Note: Applies to device variants featuring supply voltage with characteristic
value PP:
Exclusively use a PoE power supply unit with galvanic isolation.
Hirschmann has tested the power supply unit PC150/110V/54V and
recommends its use. You find the order number for the power supply unit,
which is available as accessory, under:
“Accessories” on page 57
Note: For use cases according to EN 50155, exclusively use external front
end power supply units of type PC150/110V/54V, or else the suitability of the
device for this use case is void.
WARNING
ELECTRIC SHOCK
Connect only a supply voltage that corresponds to the type plate of your
device.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
