Installation OCTOPUS OS3
Release 03 08/2020
47
Back-up fuse for each voltage input Nominal rating: max. 20 A
Characteristic: slow blow
Peak inrush current 8 A
Connection for functional ground See “Grounding the device” on page 36.
Current integral I²t <1.5 A²s
Max. PoE power Nominally 60 W
a. When using the supplied plug.
Supply voltage with the characteristic value M9
Rated voltage range 110 V AC ... 230 V AC, 50 Hz ... 60 Hz
Voltage range including maximum
tolerances
88 V AC ... 265 V AC, 47 Hz ... 63 Hz
Connection type 5-pin, “K”-coded M12 plug
Tightening torque 5.3 lb-in (0.6 Nm)
Wire diameter AWG16 (1.5 mm²)
a
a. When using the supplied plug.
Power loss buffer PoE:
110 V non-PoE:
230 V non-PoE:
>13 ms
>50 ms
>110 ms
Overload current protection on the device Non-replaceable fuse
Back-up fuse for each voltage input Nominal rating: max. 20 A
Characteristic: slow blow
Peak inrush current 3.5 A
Connection for protective grounding See “Grounding the device” on page 36.
Current integral I²t non-PoE <1.5 A²s
PoE <1 A²s
Max. PoE power Nominally 60 W
Table 21: Supply voltage with characteristic value M9
Supply voltage with the characteristic value N9
Rated voltage 72 V DC ... 110 V DC
Voltage range including maximum
tolerances
50.4 V DC ... 138 V DC
Connection type 5-pin, “K”-coded M12 plug
Tightening torque 5.3 lb-in (0.6 Nm)
Wire diameter AWG16 (1.5 mm²)
a
Power loss buffer PoE:
72 V non-PoE:
110 V non-PoE:
>11 ms
>16 ms
>40 ms
Overload current protection on the device Non-replaceable fuse
Back-up fuse for each voltage input Nominal rating: max. 20 A
Characteristic: slow blow
Peak inrush current 3.5 A
Connection for protective grounding See “Grounding the device” on page 36.
Table 22: Supply voltage with characteristic value N9
Supply voltage with characteristic value QQ
Table 20: Supply voltage with characteristic value QQ
