Installation OCTOPUS OS3
Release
03
08/2020
Figure 10: Dimension drawings: Device variants with 8 × 10/100/1000 Mbit/s twisted pair ports
R 2,5
R 0.09
323,6
12.74
77,2
3.04
77,2
3.04
90
3.54
188
7.40
197,5
7.78
8
0.31
79,2
3.12
137,5
5.41
mm
in
48,5 1.91
