VAV – Module NMV-D2M
N-A5.3 File structure
The log file contains the following columns:
N-A5.3.1 File name
When a log file is generated it is given a unique name as follows:
- Structure: NMVD2M_JJJJMM.txt
e.g.: NMV-D2M_200206.txt for year 2002, month June
The structure of the name is fixed and cannot be changed by the user.
Column Description Explanation
Date Date log entry Time / Date, when ?
Time Time log entry "
Serial number Serial Number of NMV-D2M Identification, which ?
OEM [Box-Type] OEM information "
Position Plant designation "
Action Read / Write / Reset to OEM defaults User action, what ?
Calibration Value Calibration data For manufacturer only
Calibration flow [%] Calibration data For manufacturer only
V'nom [m³/h] Nominal flow Operating flow
V'max [m³/h] V’max s etting "
V'max [%] " "
V'min [m³/h] V’min s etting "
V'min [%] " "
V'mid [m³/h] V’mid s etting "
V'mid [%] " "
Direction of rotation [open]
Direction of damper rotation Actuator setting
MP-Address NMV-D2M address setting "
Mode Mode setting: 0...10 / 2...10 V "
Setpoint [w] “ variable setting, setpoint signal w "
Volumetric flow signal [U5]
“ variable setting, actual value signal U5 "
Active alarms Active alarms Alarm / Operating data
Operating time Operating time "
Active time Active time "
Stop && Go ratio Stop & Go ratio "
Result1 Parameter field Internal parameters
Result2 " "
Result3 " "
Result4 " "
Result5 " "
Type NMV-D2M xxx [customised version] Controller type
Firmware SW version "
Config. Table-ID Configuration table "
Short mark User’s initials Project data <F4>
Project Project designation "
Comment Remarks "
Adaption Actuator Adaption behaviour Actuator setting
Synchronisation Actuator Synchronisation behaviour "
Torque [Nm] Actuator torque setting "
Column headings for log data window
The preset programming lan
guage governs the language
used for the column headings -
they are also used for
the displays in the log data window. Therefore, a new
language setting will only become effective for the log
data display when the next month file is generated.
