VAV – Module NMV-D2M
N-S4.3 Trend Recall <F6>
Previously stored data is read from the hard disk and displayed on the
screen.
N-S4.3.1 Read Trend file
The Trend window is opened from the ‘NMV-D2M ¦ Trend Recall’ menu
<F6> or the toolbar. The ‘READ DATA’ button opens a browse window
with access to all available drives.
Default path:
as set under ’EXTRAS ¦ OPTIONS ¦ NMV-D2M’.
The browser window is used in the same way as the Explorer application
of the PC operating system.
Hints:
- this function allows lists, detail displays, etc.
- highlight the required trend file and right clicking on it will open a list with
available options:
Print Trend data
Two options can be used::
- Print Print actual Trend file
- Multi Print... selection and print of several files
How does multi selection work
- click at the requested file while pressing the <Ctrl> button
- activate ‘Print’
.
‘Trend Recall’
start from toolbar:
number of trend files will be accumulated.
Therefore, after plotting, it is advisable to:
- transfer the data to a project directory
- delete the data if it is no longer needed
The appropriate file might now
be deleted, renamed, etc. as
required. Direct copying to
floppy disk or transmission by
e-mail are very simple proce-
dures
