Belkin G+MIMO User Manual

73
G+ MIMO Wireless Modem Router
SECTIONSTable of Contents 1 2 3 4 5 6 8 9 107
MANUALLY CONFIGURING NETWORK SETTINGS
5. If “Manually” is selected,
your Router will need to
be set up for a static IP
connection type� Write the
address information in the
table below� You will need
to enter this information into
the Router�
(4)
(5)
(3)
6. If not already selected, select “Using DHCP” next to “Configure:”
(4), then click “Apply Now”�
Your network adapter(s) are now configured for use with the Router.

Belkin G+MIMO Specifications

General

Frequency Band	2.4 GHz
Antenna Type	Internal
Data Rate	54 Mbps
Wireless Standard	802.11g
Security	WEP, WPA, WPA2
Wireless Speed	54 Mbps
Ports	4 x 10/100 Mbps LAN, 1 x 10/100 Mbps WAN
