iso415R-x_D00401_00_M_XXEN / 04.2021 23
ISOMETER® iso415R
Address
(dec)
Register name Data type Bytes Mode Value/Unit/Comment Factory
setting
3008 Response value R
an1
_ext Uint16 2 RO 10…1000 [kΩ], the last response value stored via
the interface
40 kΩ
3009 Response value R
an2
_ext Uint16 2 RO 5…700 [kΩ], the last response value stored via
the interface
10 kΩ
Modbus RTU parameters (32000…32099)
32000 Device address Uint16 2 RW 1…247 Last 2 digits
of the serial
number + 100
32001 Baud rate Uint32 4 RW 9600, 19200, 38400, 57600, 115200 19200
32003 Parity Uint16 2 RW 1 = even
2 = odd
3 = none
1
32004 Stop bits Uint16 2 RW 1 = 1
2 = 2
3 = automatic
3
32006 Update permission Uint16 2 RW 0 = SW update via Modbus RTU not permitted
1 = SW update via Modbus RTU permitted
0
32007 Write access Uint16 2 RW 1 = Write access enabled
2 = Write access disabled
CAUTION! Writing of all parameters is disabled,
enabling is only possible via the T/R button!!!"
1
Relay (32100…32199)
32100 Relay mode Uint16 2 RW 1 = NO principle
2 = NC principle
2
32101 Alarm assignment test Uint16 2 RW 0 = Disabled
1 = Enabled
1
32102 Alarm assignment
device error
Uint16 2 RW 0 = Disabled
1 = Enabled
1
32103 Alarm assignment
prewarning R
an1
Uint16 2 RW 0 = Disabled
1 = Enabled
0
32104 Alarm assignment
main alarm R
an2
Uint16 2 RW 0 = Disabled
1 = Enabled
1
32105 Alarm assignment -
connection fault E/KE
Uint16 2 RW 0 = Disabled
1 = Enabled
1
32106 Alarm assignment -
connection fault L1/L2
Uint16 2 RW 0 = Disabled
1 = Enabled
1
32107 Alarm assignment
Max. C
e
/fault
Uint16 2 RW 0 = Disabled
1 = Enabled
1
Response values (33000…33099)
33000 Response value
prewarning R
an1
Uint16 2 RW 10…1000 [kΩ], step size 1 kΩ, writing is only
possible when R
an1
potentiometer is set to "Ext"
40 kΩ
33001 Response value
main alarm R
an2
Uint16 2 RW 5…700 [kΩ], step size 1 kΩ, writing is only possi-
ble when R
an2
potentiometer is set to "Ext"
10 kΩ
