Modbus settings
Address
(dec)
Register name Data type Bytes Mode Value/Unit/Comment Factory
setting
Alarm behaviour (33200
…33299)
33200 Start with alarm Uint16 2 RW 0 = Disabled
1 = Enabled
0
33201 Fault memory Uint16 2 RW 0 = Disabled
1 = Enabled
0
Time behaviour (33300
…33399)
33300 Response delay Uint16 2 RW 0…1800 [s], step size 1 s 0
33301 Delay on release Uint16 2 RW 0…1800 [s], step size 1 s 0
33302 Start-up delay Uint16 2 RW 0…1800 [s], step size 1 s 0
Monitoring functions (33400
…33499)
33400 Connection monitoring L1/L2 Uint16 2 RW 0 = Disabled
1 = Enabled
1
Device error codes (58000…58999)
58000 Number of device errors Uint16 2 RO Number of active device errors
N/A
58001
E-KE connection fault
Uint16 2 RO
Error code = 30
N/A
58002
L1/L2 connection fault
Uint16 2 RO
Error code = 40
N/A
58003
Error rmware version too old
Uint16 2 RO
Error code = 321
N/A
58004
Error no rmware information
Uint16 2 RO
Error code = 325
N/A
58005 Error measurement technol-
ogy timeout (C
e
too high or
disturbances in the system)
Uint16 2 RO
Error code = 405
N/A
58006
Calibration error
Uint16 2 RO
Error code = 600
N/A
58007
Write protection error
Uint16 2 RO
Error code = 631
N/A
58008
Read protection error
Uint16 2 RO
Error code = 651
N/A
58009 Error measurement technol-
ogy HW
Uint16 2 RO
Error code = 820
N/A
58010
Error internal voltage 24 V
Uint16 2 RO
Error code = 843
N/A
58011
Error internal voltage 3.5 V
Uint16 2 RO
Error code = 846
N/A
58012
Error internal voltage V
ref
3.3 V
Uint16 2 RO
Error code = 849
N/A
58013
Error RAM microcontroller
Uint16 2 RO
Error code = 920
N/A
Control commands (59000…59999)
59000 NFC Uint16 2 RW 0 = Disabled
1 = Enabled (automatic disabling
after 15 min)
Disabled
59001 Relay test Uint16 2 RW 0 = Disable relay (automatic return to normal
operating mode after 60 s)
1 = Enable relay (automatic return to normal
operating mode after 60 s)
2 = Relay test inactive (normal operating mode)
Relay test
inactive
