Bender ISOMETER iso415R User Manual

iso415R-x_D00401_00_M_XXEN / 04.2021 25
ISOMETER® iso415R
Address
(dec)
Register name Data type Bytes Mode Value/Unit/Comment Factory
setting
Control commands (60000)
60000 Function selection Uint16 2 WO Function selection register to control the
function of the following registers. Only
specied values are permitted.
2 = Find device
4 = Reset to factory settings /
Reset parameters
6 = Test
7 = Reset
N/A
Function 2: Find device
60000 Function selection Uint16 2 WO 2 → Selection of the "Find device"
function
N/A
60001 Pattern value part 1 Uint16 2 W0 61918 → Safety pattern must be written
for the function to be executed
N/A
60002 Pattern value part 2 Uint16 2 W0 0 → Safety pattern must be written for the
function to be executed.
N/A
60003 Period Uint16 2 W0 0…300 → Period in seconds during which
the device lights up. If the device receives
the value "0", the function is stopped.
N/A
Function 4: Reset to factory settings/Reset parameters
60000 Function selection Uint16 2 WO 4 → Selection of "Reset to factory
settings/Reset parameters" function
N/A
60001 Pattern value part 1 Uint16 2 WO 64199 → Safety pattern must be written
for the function to be executed
N/A
60002 Pattern value part 2 Uint16 2 WO 1304 → Safety pattern must be written for
the function to be executed
N/A
60003 Type of reset Uint16 2 WO 1 → Reset to factory settings including
interface parameters
2 → Reset to factory settings excluding
interface parameters
N/A
Function 6: Test
60000 Function selection Uint16 2 WO 6 → Selection of the "Test" function N/A
60001 Pattern value part 1 Uint16 2 WO 32343 --> Safety pattern must be written
for the function to be executed
N/A
60002 Pattern value part 2 Uint16 2 WO 0 → Safety pattern must be written for the
function to be executed
N/A
60003 Type of test Uint16 2 WO 1 → Start IMD test N/A
