LINETRAXX® RCM420
4.4 Display in standard mode
By default, the currently measured residual current is displayed. The current response values I1 (prewarning)
and I2 (alarm) can be displayed using the Up and Down key. Press the Enter key to return to the measured
value.
M
m
A
I
2
m
A
>
M
I
1
m
A
>
In the standard mode, the currently set response values I1 and I2 can be displayed using the Up and Down
keys.
4.5 Display in menu mode
AL
out
t
SEt
InF
HiS
ESC
M
m
A
t > 1,5 s
t > 1,5 s
t > 1,5 s
t < 1,5 s
t < 1,5 s
ESC
Parameter query and setting: overview
Menu item Adjustable parameter
AL
Response values query and setting
•
Residual currentI2 (I
Δn2
) (AL2)
•
Residual currentI1 (I
Δn1
) (AL1)
•
Hysteresis of the response: % Hys
RCM420_D00057_06_M_XXEN/12.2023 17
