Bender RCMA423 User Manual

Operation and setting
22
RCMA423_D00063_03_M_XXEN/03.2021
5.5 Display in menu mode
5.5.1 Parameter query and setting: overview
Menu
item
Adjustable parameter
AL
Response values query and setting:
– Residual current I2 (I
Δn2
) (AL2)
– Residual current I1 (I
Δn1
) (AL1)
– Hysteresis of the response values: % Hys
out
Configuration of the fault memory and the alarm relay:
– Activate/deactivate the fault memory or assign
continuous mode (on/off/con)
– Select N/O operation (n.o.) or N/C operation (n.c.)
individually for each K1/K2
– Specify the number of the reload cycles
– Assign the alarm category I1 (I
Δn1
) or I2 (I
Δn2
), relay test
or device error individually to K1/K2 (1, r1/ 2, r2).
t
Set delays:
– Response delay t
on1
/t
on2
– Start-up delay t
– Delay on release t
off
(LED, relay)
SEt
Device control parameter setting:
– Select the appropriate parameter for response values:
overcurrent mode (HI), undercurrent mode (Lo) or win-
dow mode (In).
– Enable or disable password protection, change the pass-
word.
– Restore factory settings.
– Service menu SyS blocked
InF Query hard and software version
HiS Query the first stored alarm value
ESC Move to the next higher menu level (back)
